VISION DVSC-TM-14E DOOSAN 300419-00035b DN Solutions AC Servo drive 14A 2.5kW

Buy online your VISION DVSC-TM-14E DOOSAN 300419-00035b DN Solutions AC Servo drive 14A 2.5kW reference DVSC-TM-14E from our e-store Cnc-shopping, specialist in CNC machine-tools spare parts.

Servo drive dedictated for For Turret or  Tool magazine of Machine-tools such as Doosan or any other builder.

This unit is an AC servo drive engineered for DOOSAN / DN Solutions machine tools. It supplies controlled power and closed-loop regulation to matched servo motors in the 2.5 kW class with a 14 A rating, keeping axis motion stable and repeatable on turning centers and machining centers. It is commonly sourced as a replacement unit or spare part for maintenance teams supporting the Doosan VISION platform.

The DVSC-TM-14E regulates current and speed for the motor while handling feedback signals for precise positioning. In a typical cabinet, this drive works alongside the CNC controller and I/O, providing the torque response required for axis moves and contouring. Properly matched to the motor size, it helps maintain smooth feed motion and reduces nuisance following errors on older and newer DN Solutions machines.

Identification is straightforward using the printed code DVSC-TM-14E and the Doosan part reference 300419-00035b. When planning a field replacement, match the 14 A class and 2.5 kW power range to the existing axis motor and verify connector style and cabinet slot. This model is widely used on Doosan equipment where the VISION DVSC series is installed, making it a practical CNC replacement component during corrective or preventive maintenance.

Built in South Korea, the drive is designed for continuous operation in production-floor environments where temperature, dust and vibration require robust OEM hardware. Correct pairing with the specified motor family and controller helps maintain consistent homing, interpolation and rapid traverse behavior across shifts.

Reference: DVSC-TM-14E

Manufacturer: DOOSAN / DN Solutions

Product type: AC servo drive for Doosan VISION DVSC series TM- Series

Main function: Power and control of an AC servo motor in the 2.5 kW class with a 14 A rating for CNC axis motion

Applications: Axis control on DOOSAN and DN Solutions machining centers and lathes using VISION DVSC hardware, retrofit and field replacement

Key technical data: Rated up to 14 A with approx 2.5 kW power class, Doosan code 300419-00035b, manufactured in South Korea. Fast dispatch targeted within about 3 days depending on inventory.

In real shop conditions, this model is selected to restore axis drive function after trips, overcurrent faults or non-start conditions. Many maintenance teams keep a stocked spare to shorten downtime during unplanned stops. It also serves well in retrofit tasks when aligning power class and interface details with the existing cabinet. As a replacement unit, it helps bring machines back online quickly while you schedule any deeper diagnostics on the removed drive.

A standard warranty applies to support your maintenance operations.

This model can be used as an emergency spare to cut unexpected downtime on legacy DOOSAN installations for your Turret or Magazine. Cnc-shopping can also assist with repair service or an exchange service when available, which helps keep older machines productive when the original part becomes an obsolete part or hard to source.

Frequently asked questions about DVSC-TM-14E:

How do I confirm compatibility on my machine cabinet?
Check the code DVSC-TM-14E and the Doosan reference 300419-00035b against your existing drive label, then verify the 14 A and 2.5 kW class match the axis motor. Confirm connector style and physical location in the cabinet before planning the swap. Newer version can be provided as model sucessor.

Is this a drop-in replacement for the same code drive?
When the codes match and the power class is identical, it is typically used as a drop-in replacement. Follow the machine builder documentation or maintenance manual to align parameters and verify motor feedback compatibility during commissioning.

Which motors can this DOOSAN DVSC - TM Series unit operate?
It is intended for DOOSAN specified AC servo motors in the corresponding power class. Always pair it with the motor models approved for the DVSC series and confirm cable and feedback wiring per the service manual.

What is the expected lead time for shipment?
Dispatch is generally targeted within about 3 days, depending on inventory and test bench scheduling.
